Kuriyama

  2. Partners
  3. Kuriyama
Request Information
Unit of Measure

General Applications

General Applications

 N/A
  • Drag and transport lines for slurry/manure injection and spreading
  • Irrigation feeding line
  • Traveler irrigators

Construction

Construction

 N/A Green polyurethane (TPU) hose using an extruded through-the-weave process with circular woven high tenacity polyester reinforcement.

Service Temperature Range

Service Temperature [Min]

 N/A -50 ºC-58 ºF

Service Temperature [Max]

 N/A 65 ºC150 ºF

Intermittent Service Temperature Range

 N/A 79 ºC175 ºF

Features and Advantages

Features and Advantages

 N/A
  • Premium Polyurethane (TPU) Material - Exhibits exceptional resistance to abrasion, allowing for use in applications where severe abrasion is a factor and providing longer service life versus rubber or PVC hoses. Also, exhibits exceptional resistance to oils and petroleum based products.
  • Unique Woven Construction - Specially designed weave pattern provides resistance to snaking, kinking, stretching and twisting.
  • Longer Lengths - Manufactured in special 660 foot lengths to reduce possible leaking points.
  • Smooth TPU Tube - Provides low friction loss.
  • Compact Design - Flat hose design rolls up into tight coils for easy storage and transport, takes up less space than other hoses.

Nominal Specifications

Size

 N/A 4 in101.6 mm

Hose ID

 N/A 4.110 in104.4 mm

Wall Thickness

 N/A 0.140 in

Working Pressure at 68ºF

 N/A 245 psi

Burst Pressure at 68ºF

 N/A 605 psi

Coil Length

 N/A 660 ft

Tensile Strength

 N/A 28,900 lb

Weight

 N/A 0.87 lbs/ft

Specifications

Brand

 N/A Kuriyama

Type

 N/A Drag Hose

Series

 N/A OFDG

Material

 N/A Polyurethane

Note

Note

 N/A This is a non-stock product. Minimum order requirements may apply. Contact Kuriyama customer service for details.
