Series Number |
Size Code |
ID |
OD |
Max. Working Pressure at 70 oF (20 oC) |
Max. Working Pressure at 122 oF (50 oC) |
Standard Length |
Weight Per Pkg. |
|---|---|---|---|---|---|---|---|
| A1243H-04X300 | N/A 04 | N/A 1/4 in6.5 mm | N/A 0.625 in15.9 mm | N/A 250 psi | N/A 150 psi | N/A 300 ft | N/A 42 lb |
| A1243-04X500 | N/A 04 | N/A 1/4 in6.5 mm | N/A 0.500 in12.7 mm | N/A 250 psi | N/A 150 psi | N/A 500 ft | N/A 40 lb |
| A1243H-06X300 | N/A 06 | N/A 3/8 in9.5 mm | N/A 0.688 in17.5 mm | N/A 250 psi | N/A 150 psi | N/A 300 ft | N/A 43 lb |
| A1243H-08X300 | N/A 08 | N/A 1/2 in12.7 mm | N/A 0.840 in21.3 mm | N/A 250 psi | N/A 150 psi | N/A 300 ft | N/A 66 lb |
