  • KAF---Port-type-ISO
    The Alfagomma UQD & UQDB quick-connect coupling series is an essential component for liquid cooling systems in data centers. With a focus on secure and easy connections, leak-proof design, high flow rates, and resistance to mechanical stresses, it is tailored to meet the rigorous demands of data centre liquid cooling.
1 - 6 of 6 | Results Per Page | View | Unit of Measure
1
Request Information Compare Items

Part Number

Hose ID

Male Thread Type

A

B

C

S1

S2

KAF-16-BP N/A 1.00 in N/A 1-11 BSPP N/A 0.71 in18.0 mm N/A 2.93 in60.8 mm N/A 2.19 in55.7 mm N/A 1.61 in41 mm N/A 1.61 in41 mm
KAF-24-BP N/A 1.50 in N/A 1-1/4-11 BSPP N/A 0.79 in20.0 mm N/A 3.33 in84.5 mm N/A 4.09 in104.0 mm N/A 2.76 in70.7 mm N/A 2.56 in65 mm
KAF-32-BP N/A 2.00 in N/A 2-11 BSPP N/A 0.94 in24.0 mm N/A 3.33 in84.5 mm N/A 4.45 in113.0 mm N/A 2.95 in75 mm N/A 2.56 in65 mm
KAF-16-MB N/A 1.00 in N/A 1-5/16-12 MORB N/A 0.71 in18.0 mm N/A 2.93 in60.8 mm N/A 2.19 in55.7 mm N/A 1.61 in41 mm N/A 1.61 in41 mm
KAF-24-MB N/A 1.50 in N/A 1-7/8-12 MORB N/A 0.79 in20.0 mm N/A 3.33 in84.5 mm N/A 4.09 in104.0 mm N/A 2.76 in70.7 mm N/A 2.56 in65 mm
KAF-32-MB N/A 2.00 in N/A 2-1/2-12 MORB N/A 0.94 in24.0 mm N/A 3.33 in84.5 mm N/A 4.45 in113.0 mm N/A 2.95 in75 mm N/A 2.56 in65 mm
